Operating

Using The POWER FLOW

Starting POWER FLOW

Whenever the PTO is engaged to start the mower deck, the POWER FLOW will automatically start. (See tractor operator’s manual for PTO operating instructions.)

Stopping POWER FLOW

Whenever the tractor PTO is disengaged to stop the mower deck, the POWER FLOW will automatically stop.

Unplugging Mower, Bagger, or Material Collection System

c CAUTION: Avoid injury! Do not attempt to unplug attachment with machine running. • Rotating blades are dangerous. Shut off the engine and remove the key before getting off the seat to inspect the machine and attachment. • Thrown objects can cause serious injury. Make sure all machine parts are stopped before raising hopper top or removing chutes.

Checking For Plugging While Driving

Check the flow indicator on MCS chute (if equipped) periodically for any indication of loss of air flow.

If grass builds up in front of mower discharge chute, check for plugged chute or problems with blower assembly (if equipped).

If there is a trail of clippings behind mower or clippings blow to the side, check for plugged chute, full collector bags, or problems with blower assembly.

Removing Debris From Inspection Points:

1. Park machine safely. Wait for all moving parts to stop before getting off to inspect machine.

2. Open hopper cover. Check chute outlet.

3. Remove chute from mower deck or blower assembly. Check chute inlet.

4. Check under mower deck for debris.
