Safety Labels
Understanding The Machine Safety Labels
The machine safety labels shown in this section are placed in important areas on your machine to draw attention to potential safety hazards.
On your machine safety labels, the words DANGER, WARNING, and CAUTION are used with this safety-alert symbol. DANGER identifies the most serious hazards.
The operator’s manual also explains any potential safety hazards whenever necessary in special safety messages that are identified with the word, CAUTION, and the safety-alert symbol.
WARNING - ROLLOVER OR FALLING OFF MAY CAUSE DEATH
• Drive very slowly when turning.
• Always use brake going down a slope. Vehicle can take-off (freewheel) downhill.
500 lb (227 kg) in TS, TE
600 lb (272 kg) in TX, TX TURF
1000 lb (454 kg) in TH 6x4
1200 lb (544 kg) in TH 6x4 DIESEL
• Spread load evenly. Tie load down.
• Reduce speed and load on rough or hilly ground.
WARNING
YOUNG DRIVERS INCREASE CHANCE OF DEATH
• Young drivers may not be able to control vehicle.
• No drivers younger than 16 years old.
CAUTION
BEFORE LEAVING VEHICLE:
WARNING
AVOID INJURY FROM EXPLOSION
• Do not place gas container inside cargo box bed when filling.
• Place gas container on ground when filling.
WARNING M150930
RIDERS CAN FALL OFF AND BE KILLED
• Maximum of one person to a seat
• No riders in box or anywhere else
WARNING M117554
DANGER M128699
Picture Note: Located on battery
• Shield eyes, explosive gases can cause blindness or injury.
• Sulfuric acid can cause blindness or severe burns.
• Flush eyes immediately with water. Get medical help fast.
• Keep out of reach of children.
• Keep vent caps tight and level.
Emission Control System Certification Label
c CAUTION: Avoid injury! Statutes providing severe penalties for tampering with emissions controls may apply at the user’s location.
|
The emissions warranty described in the warranty section applies only to those engines marketed by John Deere that have been certified by the United States Environmental Protection Agency (EPA) and/or California Air Resources Board (CARB); and used in the United States in non-road mobile (self-propelled or portable/transportable1) equipment. The presence of an emissions label like the one shown signifies that the engine has been certified with the EPA and/or CARB. The EPA and CARB warranties only apply to new engines having the certification label affixed to the engine and sold as stated above in the geographic areas governed by the regulating agencies.
NOTE: The hp/kW rating on the engine emissions certification label specifies the gross engine hp/kW, which is flywheel power without fan. In most applications this will not be the same rating as the advertised vehicle hp/kW rating.
SAE J2258 and ASME B56.8 Compliance
This vehicle conforms to SAE J2258.
With installation of the optional horn kit, this vehicle conforms to ASME B56.8.
Warning M159705
Picture Note: This label is required and installed on machines sold in California. This label may also be installed on machines sold in other locations.
Operation of This Equipment May Create Sparks that Can Start Fires Around Dry Vegetation. A Spark Arrestor May be Required. The Operator Should Contact Local Fire Agencies For Laws or Regulations Relating to Fire Prevention Requirements.
