Safety Labels

Understanding The Machine Safety Labels

The machine safety labels shown in this section are placed in important areas on your machine to draw attention to potential safety hazards.

On your machine safety labels, the words DANGER, WARNING, and CAUTION are used with this safety-alert symbol. DANGER identifies the most serious hazards.

The operator’s manual also explains any potential safety hazards whenever necessary in special safety messages that are identified with the word, CAUTION, and the safety-alert symbol.

CAUTION

To avoid injury, use caution when operating vehicle with box sides down. Sides can strike objects or bystanders.

WARNING - ROLLOVER OR FALLING OFF MAY CAUSE DEATH

M117672

• Read operator’s manual.

• Drive very slowly when turning.

• Always use brake when going down a slope. Vehicle can take-off (freewheel) downhill.

• No loads heavier than 500 lbs (227 kg) in 4x2, 800 lbs (363 kg) in 6x4 and 1000 lbs (454 kg) in 6x4 DIESEL.

• Spread load evenly. Tie load down.

• Reduce speed and load on rough or hilly ground.

WARNING

M155337

AVOID CRUSHING

• Keep Occupant Protective Structure fully extended

• Do not jump if machine tips

• Use seat belts

When structure must be down:

• DO NOT use seat belts

• Drive with extra care

OCCUPANT PROTECTIVE STRUCTURE

To maintain occupant protection and OPS certification:

• Replace damaged OPS and worn seatbelts. Do not repair or revise.

• Any alteration of OPS must be approved by manufacturer.

CAUTION

MX2878

To avoid injury, stop engine and set parking brake before leaving vehicle.

CAUTION

M117679

HELP PREVENT INJURY WHEN DUMPING LOADS

• Operate dump with machine stationary and parking brake locked.

Never dump while moving

• Operate dump on level ground only

• Operate dump from operator’s seat only

• Do not place hands behind seat when lowering box

• Refer to Operator’s Manual for correct load distribution

WARNING

M117554

Hot surface

DANGER - CAUTION

M128699

Picture Note: Located on battery

• Shield eyes, explosive gases can cause blindness or injury.

• No sparks, flames, smoking.

• Sulfuric acid can cause blindness or severe burns.

• Flush eyes immediately with water. Get medical help fast.

• Keep out of reach of children.

• Do not tip.

• Keep vent caps tight and level.

Emission Control System Certification Label

c CAUTION: Avoid injury! Statutes providing severe penalties for tampering with emissions controls may apply at the user’s location.

The emissions warranty described in the warranty section applies only to those engines marketed by John Deere that have been certified by the United States Environmental Protection Agency (EPA) and/or California Air Resources Board (CARB); and used in the United States in non-road mobile (self-propelled or portable/transportable¹) equipment. The presence of an emissions label like the one shown signifies that the engine has been certified with the EPA and/or CARB. The EPA and CARB warranties only apply to new engines having the certification label affixed to the engine and sold as stated above in the geographic areas governed by the regulating agencies.

NOTE: The hp/kW rating on the engine emissions certification label specifies the gross engine hp/kW, which is flywheel power without fan. In most applications this will not be the same rating as the advertised vehicle hp/kW rating.

SAE J2258 and ASME B56.8 Compliance

This vehicle conforms to SAE J2258.

With installation of the optional horn kit, this vehicle conforms to ASME B56.8.
