Safety Labels
Understanding The Machine Safety Labels
The machine safety labels shown in this section are placed in important areas on your machine to draw attention to potential safety hazards.
On your machine safety labels, the words DANGER, WARNING, and CAUTION are used with this safety-alert symbol. DANGER identifies the most serious hazards.
The operator’s manual also explains any potential safety hazards whenever necessary in special safety messages that are identified with the word, CAUTION, and the safety-alert symbol.
WARNING
ROLLOVER OR FALLING OFF MAY CAUSE DEATH
• Always use brakes going down a slope. Vehicle can take-off (freewheel) downhill.
• No loads heavier than 1000 lb (454 kg). Spread load evenly. Tie loads down.
• Reduce speed and load on rough or hilly ground.
• Maintain 14 psi (97 kPa) tire pressure front and rear.
• Do not exceed gross vehicle weight rating 3120 lb (1415 kg). Follow loading instructions in operator’s manual.
WARNING
WARNING
YOUNG DRIVERS INCREASE CHANCE OF DEATH
• Young drivers may not be able to control vehicle.
• No drivers younger than 16 years old.
CAUTION
Before Leaving Vehicle:
WARNING
AVOID INJURY FROM EXPLOSION
• Do not place gas container inside cargo box bed when filling.
• Place gas container on ground when filling.
WARNING M150930
RIDERS CAN FALL OFF AND BE KILLED
• Maximum of one person to a seat
• No riders in box or anywhere else
DANGER M128699
Picture Note: Located on battery
• Shield eyes, explosive gases can cause blindness or injury.
• Sulfuric acid can cause blindness or severe burns.
• Flush eyes immediately with water. Get medical help fast.
• Keep out of reach of children.
• Keep vent caps tight and level.
WARNING - M76637
WARNING M117554
Occupant Protective Structure Safety and Certification Label
OCCUPANT PROTECTIVE STRUCTURE
To maintain occupant protection and OPS certification:
• Replace damaged OPS and worn seat belts. Do not repair or revise.
• Any alteration of OPS must be approved by manufacturer.
CERTIFICATION
Performance certified to: SAE J2194
Deere & Company Moline, Illinois, U.S.A.
Emission Control System Certification Label
NOTE: Tampering with emission controls and components by unauthorized personnel may result in severe fines or penalties. Emission controls and components can only be adjusted by EPA and/or CARB authorized service centers. Contact your John Deere Commercial and Consumer Equipment Retailer concerning emission controls and component questions.
The presence of an emissions label signifies that the engine has been certified with the United States Environmental Protection Agency (EPA) and/or California Air Resources Board (CARB).
The emissions warranty applies only to those engines marketed by John Deere that have been certified by the EPA and/or CARB; and used in the United States and Canada in off-road mobile equipment.
Emission Compliance Period
If your engine has the emission compliance category listed on the emission control system certification or air index label, this indicates the number of operating hours for which the engine has been certified to meet EPA and/or CARB emission requirements. The following table provides the engine compliance period in hours associated with the category found on the certification label.
Canadian Electromagnetic Compatibility (EMC) Compliance
This spark ignition system complies with Canadian ICES-002.
Warning M159705
Picture Note: This label is required and installed on machines sold in California. This label may also be installed on machines sold in other locations.
Operation of This Equipment May Create Sparks that Can Start Fires Around Dry Vegetation. A Spark Arrestor May be Required. The Operator Should Contact Local Fire Agencies For Laws or Regulations Relating to Fire Prevention Requirements.
