Removing and Storing

Removing the Spreader

1. Park machine safely. See “Parking Safely” in the Safety section.

2. Remove all materials from the hopper before removing spreader from machine.

c CAUTION: Avoid injury! Keep hands, feet and other body parts away from under drawbar.

3. Remove 1/8 in. spring locking pin from hitch pin.

4. Hold spreader tow tube to remove pressure from hitch pin, then remove hitch pin from hitch clevis and rear hitch plate or drawbar on machine.

5. Pull or push spreader backward to disengage hitch clevis from machine hitch, install hitch pin in hitch clevis for storage and secure with 1/8 in. spring locking pin.

Storing Spreader

Placing into Storage

1. Thoroughly clean and lubricate spreader before storing. (see Service section.)

2. Apply touchup paint to scratches to prevent rust.

3. Inflate tires to 30 psi (2 bar) (207 kPa) maximum.

4. Store spreader in an out-of-the-way place. Spreader can be tipped upright or hung to remove weight from tires/wheels. Do not use spreader as a shelf. Placing weight on spreader can distort tires/wheels over a period of time.

Removing from Storage

1. Inflate tires to 30 psi (2 bar) (207 kPa) maximum.

2. Perform all lubrication procedures as shown in the Service section.

3. Check and adjust on/off control.

4. Review Safety and Operating sections of this manual

Storing

The spreader can be tipped upright and stored against a wall using less space:

1. Remove any loose material from hopper and fan using a brush and garden hose. The spreader should be clean and dry before storing.

2. Roll spreader to desired storage area, lift hitch clevis to pivot spreader to vertical position.
