Safety Labels

Understanding The Machine Safety Labels

The machine safety labels shown in this section are placed in important areas on your machine to draw attention to potential safety hazards.

On your machine safety labels, the words DANGER, WARNING, and CAUTION are used with this safety-alert symbol. DANGER identifies the most serious hazards.

The operator’s manual also explains any potential safety hazards whenever necessary in special safety messages that are identified with the word, CAUTION, and the safety-alert symbol.

There can be additional safety information contained on parts and components sourced from suppliers that is not reproduced in this operator’s manual.

WARNING M154111

ROLLOVER OR FALLING OFF MAY CAUSE DEATH

M154111

• Read operator’s manual.

• Drive very slowly when turning.

• Always use brake going down a slope. Vehicle can take-off (freewheel) downhill.

• No loads heavier than:

500 lb (227 kg) in TS, TE
600 lb (272 kg) in TX, TX TURF
1000 lb (454 kg) in TH 6x4
1200 lb (544 kg) in TH 6x4 DIESEL

• Spread load evenly. Tie load down.

• Reduce speed and load on rough or hilly ground.

CAUTION M150928

BEFORE LEAVING VEHICLE:

M150928

• Stop engine

• Set park brake

• Remove key

WARNING M150928

YOUNG DRIVERS INCREASE CHANCE OF DEATH

M150928

• Young drivers may not be able to control vehicle.

• No drivers younger than 16 years old.

WARNING M157240

AVOID INJURY FROM EXPLOSION

M157240

• Do not place gas container inside cargo box bed when filling

• Place gas container on ground when filling

RIDERS CAN FALL OFF AND BE KILLED

M157240

• Maximum of one person to a seat

• No riders in box or anywhere else

CAUTION M157907

HELP PREVENT INJURY WHEN DUMPING LOADS

M157907

• Operate dump with machine stationary and parking brake locked: Never dump while moving

• Operate dump on level ground only

• Operate dump from operator’s seat only

• Do not place hands behind seat when lowering box

• Refer to Operator’s Manual for correct load distribution

WARNING M118611

HOT SURFACES

M118611

• Hot Surfaces

Warning M165174

M165174

Picture Note: This label is required and installed on machines sold in California. This label may also be installed on machines sold in other locations.

Operation of This Equipment May Create Sparks that Can Start Fires Around Dry Vegetation. A Spark Arrestor May be Required. The Operator Should Contact Local Fire Agencies For Laws or Regulations Relating to Fire Prevention Requirements.

DANGER M128699

M128699

Picture Note: Located on battery

• Shield eyes, explosive gases can cause blindness or injury.

• No sparks, flames, smoking.

• Sulfuric acid can cause blindness or severe burns.

• Flush eyes immediately with water. Get medical help fast.

• Keep out of reach of children.

• Do not tip.

• Keep vent caps tight and level.

CAUTION M165913

M165913

• Avoid equipment fires.

• Accumulation of grass, leaves and other debris on or near hot or moving parts can cause a fire.

• Inspect machine before, during and after use.

• Shut off engine and allow machine to cool before cleaning.

Inspect and clean the entire machine and pay special attention to these locations:

1. Muffler and exhaust pipes

2. Exhaust manifold and heat shields

3. Skid plate (if equipped)

4. Radiator (if equipped)

Emission Control System Certification Label

NOTE: Tampering with emission controls and components by unauthorized personnel may result in severe fines or penalties. Emission controls and components can only be adjusted by EPA and/or CARB authorized service centers. Contact your John Deere Commercial and Consumer Equipment Retailer concerning emission controls and component questions.

The presence of an emissions label signifies that the engine has been certified with the United States Environmental Protection Agency (EPA) and/or California Air Resources Board (CARB).

The emissions warranty applies only to those engines marketed by John Deere that have been certified by the EPA and/or CARB; and used in the United States and Canada in off-road mobile equipment.

Emission Compliance Period

If your engine has the emission compliance category listed on the emission control system certification or air index label, this indicates the number of operating hours for which the engine has been certified to meet EPA and/or CARB emission requirements. The following table provides the engine compliance period in hours associated with the category found on the certification label.

SAE J2258 and ASME B56.8 Compliance

This vehicle conforms to SAE J2258.

With installation of the optional horn kit, this vehicle conforms to ASME B56.8.

Canadian Electromagnetic Compatibility (EMC) Compliance

This spark ignition system complies with Canadian ICES-002.
