Safety Labels
Understanding The Machine Safety Labels
The machine safety labels shown in this section are placed in important areas on your machine to draw attention to potential safety hazards.
On your machine safety labels, the words DANGER, WARNING, and CAUTION are used with this safety-alert symbol. DANGER identifies the most serious hazards.
The operator’s manual also explains any potential safety hazards whenever necessary in special safety messages that are identified with the word, CAUTION, and the safety-alert symbol.
CAUTION M165798
• Accumulation of grass, leaves and other debris on or near hot or moving parts can cause a fire.
• Inspect machine before, during, and after use.
• Shut off engine and allow machine to cool before cleaning.
Inspect and clean the entire machine and pay special attention to these locations:
2. Exhaust manifold and heat shields
WARNING M165639
AVOID SERIOUS INJURY OR DEATH
• Driver must be at least 16 years old with a valid driver license.
• Never have more than the driver and one passenger in the vehicle.
• Both the driver and passenger must use seatbelts at all times.
• Both the driver and passenger must use helmets when driving aggressively, on rough or uneven terrain, or at higher speeds.
• Passenger must be able to grasp handholds with seatbelt on and both feet on floor.
Occupant Protective Structure Safety and Certification Label
OCCUPANT PROTECTIVE STRUCTURE
To maintain occupant protection and OPS certification:
• Replace damaged OPS and worn seat belts. Do not repair or revise.
• Any alteration of OPS must be approved by manufacturer.
CERTIFICATION
Performance certified to: SAE J2194
Deere & Company Moline, Illinois, U.S.A.
CAUTION M160916
HELP PREVENT INJURY WHEN DUMPING LOADS
• Lock park brake before dumping
• Operate dump on level ground only
• Keep hands away from cargo box
CAUTION M161015
BEFORE LEAVING VEHICLE:
WARNING M117554
WARNING M158180
ROLLOVER OR FALLING OFF CAN CAUSE INJURY OR DEATH
• Watch video and read operator’s manual before use.
• Avoid excessive speed and sharp turns.
• Be careful and slow down when loaded, on difficult terrain, operating at night or in reverse.
• Use brakes going down a slope. Vehicle can gain speed (freewheel) downhill.
• No more than one driver and one passenger.
• Keep arms and legs in during use.
• Never operate vehicle under the influence of alcohol or drugs.
• For off-road use only. Not intended for use on public roads or highways.
DANGER M128699
Picture Note: Located on battery
• Shield eyes, explosive gases can cause blindness or injury.
• Sulfuric acid can cause blindness or severe burns.
• Flush eyes immediately with water. Get medical help fast.
• Keep out of reach of children.
• Keep vent caps tight and level.
WARNING M161567
AVOID INJURY FROM EXPLOSION
• Do not place fuel container inside cargo box when filling.
RIDERS CAN FALL OFF AND BE KILLED
IMPROPER LOADING CAN CAUSE ROLLOVER
• Secure and spread loads evenly.
• Do not exceed 1000 lb (454 kg) in cargo box or 3100 lb (1406 kg) gross vehicle weight.
• Maintain proper tire pressure for load and conditions.
• Follow recommendations in operator’s manual.
Warning M165174
Picture Note: This label is required and installed on machines sold in California. This label may also be installed on machines sold in other locations.
Operation of This Equipment May Create Sparks that Can Start Fires Around Dry Vegetation. A Spark Arrestor May be Required. The Operator Should Contact Local Fire Agencies For Laws or Regulations Relating to Fire Prevention Requirements.
Emission Control System Certification Label
NOTE: Tampering with emission controls and components by unauthorized personnel may result in severe fines or penalties. Emission controls and components can only be adjusted by EPA and/or CARB authorized service centers. Contact your John Deere Retailer concerning emission controls and component questions.
The presence of an emissions label signifies that the engine has been certified with the United States Environmental Protection Agency (EPA) and/or California Air Resources Board (CARB).
The emissions warranty applies only to those engines marketed by John Deere that have been certified by the EPA and/or CARB; and used in the United States and Canada in off-road mobile equipment.
Emission Compliance Period
If your engine has the emission compliance category listed on the emission control system certification or air index label, this indicates the number of operating hours for which the engine has been certified to meet EPA and/or CARB emission requirements. The following table provides the engine compliance period in hours associated with the category found on the certification label.
