Configure Language, Units of Measure, and Color

1.
   A59565-UN-08MAR07

   Display Icon


   A63089-UN-18AUG08

   Regional Settings Icon


   A63117-UN-21AUG08

   Settings Icon


   A63084-UN-18AUG08

   Unit of Measure Icon


   H85801-UN-14JUN06

   Enter


   A63086-UN-18AUG08

   Highlight Color

   Select Menu >> Display icon >> Settings icon.

---




2. Select Regional Settings settings icon.

3. Select each drop-down box and choose a Country, Language, Numeric Format, and the Units of measure. To select different units of measure for different options, proceed as follows.

4. Select Units of Measure icon.

5. Select each drop-down box and choose a unit of measure. When complete, select Enter. To change all units back to a single type, select Regional icon >> Units drop down menu and select unit of measure.

6. Select Highlight Color icon. Select desired highlight color for selected icons.

Screen Area Information

Display Settings - Display Settings
Regional - Regional
Country - Country
Language - Language
Numeric Format - Numeric Format
Units - Units
Metric - Metric
Imperial - Imperial
US - United States
Units of Measure - Units of Measure
Distance - Distance
Area - Area
Volume - Volume
Mass - Mass
Temperature - Temperature
Pressure - Pressure
Force - Force
