Configure Date and Time

1.
   A59565-UN-08MAR07

   Display Icon


   A63117-UN-21AUG08

   Settings Icon


   A63085-UN-18AUG08

   Date and Time Icon


   H85801-UN-14JUN06

   Enter


   A63089-UN-18AUG08

   Regional Settings

   Select Menu >> Display icon>> Settings icon.

---




2. Select Date and Time icon.

3. If equipped with GPS (Global Positioning System), check the box to display a checkmark. Select Time Zone.

   1. Select each input box for hour and minutes.

   2. Select drop down box to change a.m. or p.m. Offsets are automatically determined.

   3. Select Enter.

4. If not using GPS, make sure box is unchecked.

   1. Select each Date input box and choose the month, day, and year.

   2. Select each Time input box and chose the hours and minutes.

   3. Select drop down box to select a.m. or p.m.

5. If area is currently observing daylight saving time, select Daylight Saving Time check box to display a check. When daylight saving changes, select this box to change hour reading instantly.

6. Select Regional Settings icon.

7. Select Date Format drop down box and choose desired format.

8. To use a 24 hour clock, select 24 Hour Clock check box to display a check.

Screen Area Information

Display Settings - Display Settings
Time/Date - Time and Date
Date - Date
Date Format - Date Format
MM - Month
DD - Day
YYYY - Year
Time - Time
Time Zone - Time Zone
24 Hour Clock - 24 Hour Clock
Daylight Saving Time - Daylight Saving Time
GMT Offset - Greenwich Mean Time Offset
Local Offset - Local Offset
Use GPS Time and Date - Use GPS Time and Date
