Operate the Drill with Signus Monitor System


Tramlines

A63100
A63100-UN-21AUG08

Show Tramlines

A63095
A63095-UN-21AUG08

Increase Tramline

During drill operation, tramlines adjust and operate automatically.

To display current tramline sequence, select Show Tramline button.

To adjust tramlines during operation, select Increase Tramline button.


Seed Rate

A63099
A63099-UN-21AUG08

Increase Button

A63108
A63108-UN-21AUG08

Decrease Button

During drill operation, seed rate can be adjusted from the main screen.

To increase seed rate during operation, select Increase or Decrease buttons. Seed rate adjustments are displayed on screen.

To cancel seed rate adjustments and reset to pre-determined value, select Increase or Decrease buttons until original value is displayed.


Seed Meter Shutoff

A63103
A63103-UN-29OCT08

Seed Meter Shutoff

A63105
A63105-UN-21AUG08

Right Meter Shutoff

During operation, seed meters can be temporarily shut off.

Select Seed Meter Shutoff to disable meter. If equipped with 2 meters, Seed Meter Shutoff disables left-hand meter only.

Select Right Meter Shutoff to disable right-hand meter. If equipped with one meter Right Meter Shutoff has no function.


Obstructions

    A63094
    A63094-UN-21AUG08

    Obstruction

    Obstruction feature is used to avoid damage by obstacles in the field. The following is an example if an obstacle is on the right-hand side:

  1. NOTE: Selecting Obstruction does not increase tramline settings or effect the tramline sequence.
    Select Obstruction button.
  2. Raise right-hand marker.
  3. Lower then raise left-hand marker.
  4. Drive around obstacle.
  5. Lower right-hand marker.
  6. Select Obstruction button again.
