Inspect Machine

  1. Inspect for loose, damaged, or missing parts. Repair or replace parts before entering the field. Make sure air and hydraulic hoses and electrical wires do not interfere with moving parts.

  2. Check inside tanks and remove any obstructions from meter inlet openings before filling.

  3. CAUTION: Stabilizer foot pin is under spring tension. Under no condition, should pin be removed. For service, see your John Deere dealer.

    A52201
    A52201-UN-28APR03

    A - Cotter Pin

    Ensure cotter pins (A) are installed on both ends of pin for each stabilizer foot.
