Lubrication Intervals

Lubrication Intervals
Item	Start of Season	50 Hours	150 Hours	End of Season
Hitch Jack	●			●
Wheel Pivot Bearings		●
Wheel Bearings			●
Depth Gauge Arm				●
Closing Wheel Pivot		●
Press Wheel Pivot		●
Roller Chains		●
Transmission Oil Level	●

N46421-UN-30AUG94

Jack

A66806-UN-24MAR10

Wheel Pivot Bearings

A66807-UN-24MAR10

Wheel Bearings
