Remove the Tractor Power Generation System

1. CAUTION:


   TS198-UN-23AUG88

   PTO Entanglement


   A87032-UN-31JUL15

   A - Alternator

   B - Gear Case

   C - Cap Screws

   Avoid serious injury or death. Keep driveline shields in place.

   Remove the cap screws (C) and alternator (A) from the gear case (B).

---




2. NOTE:


   A87029-UN-31JUL15

   A - Support

   B - Gear Case

   C - Cap Screws

   Leave support (A) attached unless there is interference with other attachments.

   Loosen cap screws (C) and remove the gear case (B) from the tractor.

---




3. Install any components removed earlier when installing the power generation.
