1720-Hitch Lowered
|
AG,OUO6028,848 -19-09AUG99-1/2 |
| LEGEND: | Dimension "A" With Markers |
Dimension "B" | Dimension "C" |
|---|---|---|---|
| 16-Row, 762 mm (30 in.) | 8.1 m (26 ft. 8 in.) | 7.2 m (23 ft. 2 in.) | 3.6 m (11 ft. 10 in.) |
|
|
when moving or operating this machine near electric lines to avoid contact. |
CAUTION:
Serious injury or death can result from contact with electric lines. Use care
AG,OUO6028,848 -19-09AUG99-2/2 |
