Informative Caution Messages and Reactions-Seed Counter

A41913

Informative (caution) messages display at the bottom of RUN Page 1 and are advisory in nature. Message will remain on screen until corrective action is taken.

NOTE: In SET-UP or INFO modes, these same messages will display as full page Information Warnings (shown with [i] icon).

Caution Message-Seed Counter Cause Solution
Some primaries are seeding low. One or more active sensors are counting below Low Warning Population setting for 7.5 seconds.

NOTE: Message clears automatically if rate goes above Low Warning setting for 7.5 seconds.

 Press INFO to identify LOW runs. Reset Low Warning limit, if desired.
Some primaries are seeding high. One or more active sensors counting above High Warning Population setting for 7.5 seconds.

NOTE: Message clears automatically if rate goes below High Warning setting for 7.5 seconds.

 Press INFO to identify HIGH runs. Reset High Warning limit, if desired.
Diagnostics on counting sensors. Performance of one or more sensors has degraded.

NOTE: Message clears automatically if sensor condition improves.

 Press INFO to identify sensors. Sensor lens may need cleaning.

Check for pinched or cut fiber optic cables.

Press INFO, Counter Status, and check channels.
Check that sensors are plugged in.
Some counting sensors are OFF! One or more sensors are turned off. Press SET-UP and turn sensors ON.
Some counting sensors are ignored! One or more sensors are being ignored. Turn main clutch off and on to reactivate sensor(s).
Invalid seed type, counter disabled! One or more sensors are not on top primary bank, or two different crop types are being fed into sensor or fertilizer is being fed into sensor. Correct primary run routing.

Correct crop type in Air Cart Set-Up mode.

Stop single-shooting two products through top runs.
