Every 10 Hours or Daily

OUO6074,0000224 -19-20FEB01-1/3

Fill crankcase of pump with TY6296 SAE 80/90 W EP gear oil or equivalent at fill port (A). Fill crankcase level to check port (B). Check level daily thereafter.

A-Fill Port
B-Check Port

OUO6074,0000224 -19-20FEB01-2/3

Check fertilizer strainer screen (A) after initial start up of pump and daily thereafter. Clean when necessary.

A-Screen

OUO6074,0000224 -19-20FEB01-3/3
