| 1700 SERIES PLANTER FERTILIZER MATRIX - TO ENSURE ROW TO ROW RATE CONSISTENCY FOR LIQUID FERTILIZER ATTACHMENT WITH PISTON PUMP |
| DELIVERY SYSTEM |
FRAME MOUNTED SINGLE DISK OPENER |
UNIT MOUNTED DOUBLE DISK OPENER |
SINGLE DISK UNIT MOUNTED INJECTION OPENER |
FRAME MOUNTED DOUBLE DISK OPENER |
LESS OPENERS |
| LOW PRESSURE FLOW DIVIDER DELIVERY SYSTEM - 1770 NT, 1770 NT CCS, 1790 |
NO ORIFICE OR NOZZLE REQUIRED. OPTIONAL 1 PSI CHECK VALVES REQUIRED FOR APPLICATION RATES OF 10 GPA OR LESS. SHORTEST DELIVERY HOSE LINE MUST NOT BE ANY SHORTER THAN 1/2 THE LENGTH OF THE LONGEST HOSE. |
NO ORIFICE OR NOZZLE REQUIRED. OPTIONAL 1 PSI CHECK VALVES REQUIRED FOR APPLICATION RATES OF 10 GPA OR LESS. SHORTEST DELIVERY HOSE LINE MUST NOT BE ANY SHORTER THAN 1/2 THE LENGTH OF THE LONGEST HOSE. |
NOT AVAILABLE |
NOT AVAILABLE |
LOW PRESSURE SYSTEMS NOT COMPATIBLE WITH SYSTEMS USING ORIFICES OR NOZZLES; NO ORIFICE OR NOZZLE REQUIRED. OPTIONAL 1 PSI CHECK VALVES REQUIRED FOR APPLICATION RATES OF 10 GPA OR LESS. SHORTEST DELIVERY HOSE LINE MUST NOT BE ANY SHORTER THAN 1/2 THE LENGTH OF THE LONGEST HOSE. |
| HIGH PRESSURE CENTRAL MANIFOLD DELIVERY SYSTEM - 1770 NT, 1770 NT CCS, 1790 |
NOT AVAILABLE |
NOT AVAILABLE |
PROPER NOZZLE REQUIRED FOR RATE AND TRAVEL SPEED - PRESSURE TO BE BETWEEN 20 AND 70 PSI. NO ORIFICES REQUIRED. |
NOT AVAILABLE |
HIGH PRESSURE SYSTEM SHOULD BE USED WITH OPENERS OR DELIVERY SYSTEMS REQUIRING ORIFICES OR NOZZLES. PROPER ORIFICE OR NOZZLE REQUIRED FOR RATE AND TRAVEL SPEED. |
| PIPE MANIFOLD DELIVERY SYSTEM - 1700, 1710, 1720, 1750, 1760, 1760NT, 1770 12NR, 1770 12NF |
PROPER ORIFICE REQUIRED FOR RATE AND TRAVEL SPEED - PRESSURE TO BE BETWEEN 20 AND 70 PSI. |
PROPER ORIFICE REQUIRED FOR RATE AND TRAVEL SPEED - PRESSURE TO BE BETWEEN 20 AND 70 PSI. |
PROPER NOZZLE REQUIRED FOR RATE AND TRAVEL SPEED - PRESSURE TO BE BETWEEN 20 AND 70 PSI. NO ORIFICES REQUIRED. |
PROPER ORIFICE REQUIRED FOR RATE AND TRAVEL SPEED - PRESSURE TO BE BETWEEN 20 AND 70 PSI. |
PROPER ORIFICE REQUIRED FOR RATE AND TRAVEL SPEED - PRESSURE TO BE BETWEEN 20 AND 70 PSI. ORIFICES TO BE REMOVED FOR INJECTION OPENERS WITH NOZZLES. |
