Preparing for Storage

IMPORTANT: Wings may gradually lower if pressure is not relieved from wing fold hydraulic cylinders. Temperature increases or sunlight can cause thermal expansion of hydraulic fluid. Always relieve

pressure before parking or storing machine.

1. If machine will be stored with wings in folded position, relieve hydraulic pressure in wing fold cylinders before disconnecting.

OUO6023,0001714 -19-10FEB05-1/4

2. Clean and store machine on a hard surface in a dry place, if possible. If storing on a soft surface, place a wood board under openers to prevent them from penetrating and resting in the ground.

3. Lubricate entire machine. See Lubrication and Maintenance section.

4. Inspect for loose or damaged parts; replace and tighten as required.

5. Repaint scratches as necessary to prevent rust.

6. Coat disks with oil or grease, then lower onto a wood board for storage.

7. Apply grease to exposed areas of hydraulic cylinder rods.

8. Place hose ends and warning light plug in storage positions on hitch.

N45734

Hose and Light Plug Storage

OUO6023,0001714 -19-10FEB05-2/4

9. Empty tanks and clean out caked deposits.

· Compressed Air (Dry) Cleaning:

causym CAUTION: Reduce compressed air to less than 210 kPa (2 bar) (30 psi) when using for cleaning purposes. Clear area of bystanders, guard against flying debris, and wear personal protection equipment, including eye protection.

IMPORTANT: Compressed air (dry) cleaning method is recommended to prevent gum-like deposits (left by water wash) from forming on components and/or blocking air passages.

10. Thoroughly clean inside of tanks and meter boxes using compressed air. A good dry cleaning is preferable to poor washing and drying.

· Water Wash (Wet) Cleaning:

causym CAUTION: Do not allow residue from tank washing to contaminate well or ground water.

IMPORTANT: If compressed air is not available for cleaning, water wash method may be used, provided meter boxes and rollers are thoroughly dried after cleaning. Drying takes time since moisture trapped in bearing areas is slow to drain or evaporate.

Do not power wash a machine with product in tank.

11. Wash machine thoroughly, inside and out. Wipe surfaces and components dry.

TS266

OUO6023,0001714 -19-10FEB05-3/4

causym CAUTION: Be careful when using diesel fuel so that it does not ignite. Use only in well ventilated areas, away from any sparks and flames, to prevent being seriously injured or killed by fire.

12. Remove chains from meter drive system. Clean chains with diesel fuel, coat with John Deere Multipurpose Spray Lube TY6350 and hang in a dry place.

13. Replace any missing or damaged parts including hoses, hardware, and decals. Tighten all hardware.

OUO6023,0001714 -19-10FEB05-4/4
