Implement Code |
|
| Base Machine |
7000/8000 Series Tractors |
55 Series Tractors |
Hitch Weighta |
| Twenty-Four Row 76 cm (30 in.) Central Commodity System With PRO-SERIES™XP Row Units |
455 |
435 |
4100 kg (9000 lbs) |
| Markers |
|
| Tri-Fold |
52 |
50 |
450 kg (1000 lbs) |
| Less Markers |
|
|
|
| Wing Frame Assemblies |
|
| Four 10.00 x 15 8 PR Tires |
|
|
|
| Four 11 x 22.5 Load Rang F hi Flotation Tires |
17 |
16 |
140 kg (300 lbs) |
| Row Unit Parallel Arms |
|
| Regular |
|
|
|
| Long |
21 |
20 |
180 kg (400 lbs) |
| Liquid Tanks |
|
| Less Tank and Mounting Brackets |
|
|
|
| Insecticide Tank and Mounting Brackets |
57 |
54 |
450 kg (1000 lbs) |
| Fertilizer Pump, Delivery System and Openers |
|
| Less Pump, Delivery System and Openers |
|
|
|
| Piston Pump, Flow Divider with Hoses and Frame Mounted Single Disk Fertilizer Openers |
57 |
54 |
450 kg (1000 lbs) |
| Piston Pump, Flow Divider with Hoses, Less Openers |
|
|
|
| Piston Pump, Less Delivery System, Less Openers |
|
|
|
| Variable Rate Piston Pump, Flow Divider with Hoses and Frame Mounted Single Disk Openers |
57 |
54 |
450 kg (1000 lbs) |
| Variable Rate Piston Pump, Flow Divider with Hoses, Less Openers |
|
|
|
| Variable Rate Piston Pump, Less Delivery System, Less Openers |
|
|
|
| aDrawbar hitch weight limits of 10,000 lbs for 8000 series and 11,000 lbs for 9000 series tractors. |
