Configure Brightness, Volume, and Color

1. Select Menu >> Display button >> Display softkey.

2. Two brightness levels are available. Select Day/Night button to toggle screen brightness between day level and night level. Sun and moon images at top left of screen alternately highlight to show active selection. Select + plus and - minus buttons to adjust backlight level for Day selection. Toggle to Night selection and adjust a different backlight level with plus and minus buttons.

3. Select Instant Darken button to completely darken screen. Touch any part of screen (touchscreen only) or select any button to brighten again.

4. Select plus and minus buttons to adjust Volume indicator.

5. Select a check box to choose a Highlight Color an item changes to when selected.

6. When monitor is installed in a compatible cab, a (Synchronize) Sync With Cab check box is available. When checked, this display controls interior cab lights as well.

Screen Area Information

Display Main Display Main Backlight Backlight Volume Volume Highlight Color Highlight Color Sync With Cab Synchronize With Cab
A59565

Display Button

A59591

Display Softkey

A59594

Day / Night Button

A59595

Scale Indicator

A59593

Instant Darken Button

OUO6074,0000F45 -19-30OCT07-1/1
