Configure Planter Drive Source

Drive source is configured at the factory for each planter. The only reason to change this is if a different drive system has been installed on machine.

1. Select Menu >> Planter button >> Configure softkey >> Frame tab >> Meter / Drive Setup button >> Drive Source drop-down box.

IMPORTANT: A Drive Source change resets all planter settings to default values.

2. Select drive source.

3. Select Enter button.

NOTE: Wait 30 seconds between power cycles.

4. Cycle power.

Screen Area Information

Planter Configuration Planter Configuration Frame Frame Meter Drive Setup Meter Drive Setup Drive Source Drive Source Variable Rate Variable Rate Ground Driven Ground Driven
A59551

Planter Button

A59172

Configure Softkey

OUO6074,0000F7E -19-03OCT07-1/1
