Operate the Drill with Signus Monitor System

During drill operation, tramlines adjust and operate automatically.

To display current tramline sequence, select Show Tramline button.

To adjust tramlines during operation, select Increase Tramline button.

NS43404,00000AF -19-16OCT08-1/4

During drill operation, seed rate can be adjusted from the main screen.

To increase seed rate during operation, select Increase or Decrease buttons. Seed rate adjustments are displayed on screen.

To cancel seed rate adjustments and reset to pre-determined value, select Increase or Decrease buttons until original value is displayed.

NS43404,00000AF -19-16OCT08-2/4

During operation, seed meters can be temporarily shut off.

Select Seed Meter Shutoff to disable meter. If equipped with 2 meters, Seed Meter Shutoff disables left-hand meter only.

Select Right Meter Shutoff to disable right-hand meter. If equipped with one meter Right Meter Shutoff has no function.

NS43404,00000AF -19-16OCT08-3/4

Obstruction feature is used to avoid damage by obstacles in the field. The following is an example if an obstacle is on the right-hand side:

NOTE: Selecting Obstruction does not increase tramline settings or effect the tramline sequence.

NS43404,00000AF -19-16OCT08-4/4
