Configure Planter Drive Source

Drive source is configured at the factory for each planter. The only reason to change this configuration is if a different drive system has been installed on machine.

1. Select Menu >> Planter button >> Configure softkey >> Drives tab >> Drive Configure drop-down box >> Settings button.

IMPORTANT: A Drive Source change resets all planter settings to default values.

2. Select drive source.

3. Select Enter button to acknowledge controller reset warning.

NOTE: Wait 30 seconds between power cycles.

4. Cycle power.

5. For variable driven machines:

a. Select Menu >> Planter button >> Configure softkey >> Drives tab >> Drive Sections drop-down box >> Settings button.

b. Set number of motors, and select next page icon.

c. Configure each drive motors end row with input box.

d. Configure drive gear and driven gear using input boxes.

e. Configure clutch disconnect location using drop-down box. Select next page icon to configure other motor row clutches.

f. When complete select Enter .

Screen Area Information

Planter Configuration Planter Configuration Frame Frame Meter Drive Setup Meter Drive Setup Drive Source Drive Source Drives Drives
A59551

Planter Button

A59172

Configure Softkey

A59377

Settings Button

OUO6074,0000F7E -19-14OCT08-1/2

Start Row Starting Row End Row Ending Row Drive Gear Drive Gear Driven Gear Driven Gear

OUO6074,0000F7E -19-14OCT08-2/2
