VRD Event Logs

Use this to record system activity for a period of time during an event. Your dealer uses this to diagnose the cause of the event.

1. Select Menu >> Planter button >> Diagnostics softkey >> Tests tab.

2. Select VRD Event Logs from drop down box.

3. Select Zero button to clear all event logs.

4. Select Start button to start new event log.

5. Select Event Log button to view stored event log data.

6. Select Previous Page or Next Page buttons to view additional pages or select Go to Page input box and enter a specific page number.

Screen Area Information

Planter Diagnostics Planter Diagnostics Tests Tests Clear all event logs Clear all event logs Start new event log Start new event log Start Start Stop Stop Event log Event log Hour Meter Hour Meter Ground Speed Ground Speed Wheel Sensor Wheel Sensor Active Active Inactive Inactive Planter Position Planter Position Motor Motor Target rpm Target revolutions per minute Actual rpm Actual revolutions per minute Valve % Valve percentage Target Target Seeds Seeds ac Acre ha Hectare Left Left Right Right Open Open
A59551

Planter Button

A59567

Diagnostic Softkey

A61134

Previous Page

A61135

Next Page

A59520

Clutch

OUO6074,0001069 -19-11OCT07-1/2

Closed Closed

OUO6074,0001069 -19-11OCT07-2/2
