Ground Speed Source

1. Select Menu >> Planter button >> Configuration softkey >> Sensor tab.

2. Select Tractor Speed from drop down box.

3. Auto box checked is the recommended option. Radar speed and tractor wheel speed are shown on bottom of screen. The active source used at this moment is displayed in the middle of the screen.

4. To force the monitor to use only one speed source, clear Auto check box.

IMPORTANT: Manual speed is an option. A single speed value must be entered. The monitor assumes the planter is always travelling this speed. Travel at this speed for most accurate monitor readings. All rates and warnings are based on the speed entered, not the actual ground speed.

5. Select a single speed source; Radar , Wheel Speed , or Manual .

Screen Area Information

Planter Configuration Planter Configuration Sensors: Sensors: Sensor Sensor Tractor Speed Tractor Speed Auto Auto Select Source Select Source Active Source Active Source mph Miles Per Hour kph Kilometers Per Hour
A59551

Planter Button

A59172

Configuration Softkey

A62104

Radar Speed

A62103

Wheel Speed

A62106

Manual Speed

OUO6074,000107C -19-24JUL08-1/1
