Adjust Sensor Sensitivity

1. Select primary Menu button >> Blockage button >> Blockage Configuration softkey.

2. Select Row Fail Rate drop-down box.

3. Select a level of sensor response. This level sets the amount of time allowed between seed detections before blockage is indicated. Once seed rate is verified in the field, set the level as sensitive as possible without triggering nuisance alerts.

  • Most Sensitive: 2 Seeds per second.
  • 1 Seed per second.
  • 1 Seed every 2 seconds.
  • Least Sensitive: 1 Seed every 3 seconds.
A62278

Seeds Per Second
