Configure Tire Speed Sensor

1. Inflate cart tires to pressure recommended in operator's manual.

2. Select primary Menu button >> Air Cart button >> Configuration softkey >> Sensor tab.

3. Select Tire Speed from drop-down box. Current tire speed is displayed under drop-down box.

4. To obtain an approximate calibration, select the calibration input box and enter the travel distance of cart tire.

Tire Travel Distance
Tire Size Travel Distance
Centimeters (Inches) per Tire Revolutiona
18.4-26 R3, 10PR 419.1 (165)
18.4-26 R2, 10PR 439.4 (173)
23.1-26 R3, 10PR 452.1 (178)
28L-26 R3, 12PR 477.5 (188)
23.1-26 R2, 10PR 502.9 (198)
28L-26 R2, 12PR 508 (200)
28.1-R26 R1, 12PR 520.7 (205)
30.5L-32 R3, 12PR 535.9 (211)
30.5L-32 R2, 12PR 566.4 (223)
30.5L-32 R1, 14PR 551.2 (217)
710/70R38 R1W, 2 Star 589.3 (232)
20.8R-38 R1, 1 Star 536.9 (222)
18.4R-46 R1, 3 Star 602 (237)
18.4R42 553.7 (218)
20.8R-42 R1, 2 Star 586.7 (231)
aTire travel per revolution is estimated for properly inflated tire.



5. To obtain a more accurate calibration, perform the following:

a. Properly inflate tires.

b. Fill tanks one half full of product.

c. Mark a 122 m (400 ft.) course in the field with soil prepared for seeding as desired.

A59671

Air Cart Button

A59325

Primary Menu Button

A59672

Configuration Softkey

A59846

Calibration Button

A61929

Repeat Course

OUO6074,0000FD8 -19-04JUN08-1/2

d. Select Calibration button.

e. Approach start of course at seeding speed.

f. When front tires of tractor cross start of course, select Calibration button.

g. When front tires of tractor cross end of course, select Calibration button.

h. If the enter button appears, select it to accept calibration. If repeat course button appears, select it and repeat calibration procedure.
