Connect SeedStar™ 2 Monitor Harness

NOTE: Harness locations will vary from tractor to tractor.

A47096
A47096-UN-02FEB01

A - Monitor Harness

B - Connector

Connect SeedStar™ 2 monitor harness (A) to connector (B).

OUO6074,0000988-19-20090522
