Configure Planter Drive Source

A59325
A59325-UN-19FEB07

Menu

A59551
A59551-UN-08MAR07

Planter Button

A59172
A59172-UN-29JAN07

Configure Softkey

A59377
A59377-UN-23FEB07

Settings Button

H85801
H85801-UN-14JUN06

Enter

Drive source is configured at the factory for each planter. The only reason to change this configuration is if a different drive system has been installed on machine.

  1. Select Menu >> Planter button >> Configure softkey >> Drives tab >> Drive Configure drop-down box >> Settings button.

  2. IMPORTANT: A Drive Source change resets all planter settings to default values.

    Select drive source.

  3. Select Enter button to acknowledge controller reset warning.

  4. NOTE: Wait 30 seconds between power cycles.

    Cycle power.

  5. Configure drive sections:

    1. Select Menu >> Planter button >> Configure softkey >> Drives tab >> Drive Sections drop-down box >> Settings button.

    2. Set number of motors, and select next page icon.

    3. Configure each drive motor end row with input box.

    4. Configure drive gear and driven gear using input boxes.

    5. Configure clutch disconnect location using drop-down box. Select next page icon to configure other motor row clutches.

    6. When complete select Enter.

Screen Area Information

Planter Configuration - Planter Configuration
Drive - Drive
Drive Source - Drive Source
Meter Type - Meter Type
Motor - Motor
Start Row - Start Row
End Row - End Row
Drive Gear - Drive Gear
Driven Gear - Driven Gear
Left - Left
Right - Right
RowCommand No - RowCommand No
RowCommand Yes - RowCommand Yes

OUO6064,00001AC-19-20100615
