Calibrate Common Start and Stop Height

A59325
A59325-UN-19FEB07

Menu

A59551
A59551-UN-08MAR07

Planter Button

A59172
A59172-UN-29JAN07

Configure Softkey

A59528
A59528-UN-08MAR07

Planter Raised

A59529
A59529-UN-09MAR07

Planter Lowered

A59530
A59530-UN-08MAR07

Start/Stop

H85801
H85801-UN-14JUN06

Enter

Use this procedure to set a single point to start and stop RowCommand™ and Variable Rate Drive (VRD) motors as the machine raises and lowers. Common start/stop points are used when machine is equipped with row unit parallel-arm height switches. Machines with a wheel frame height sensor can use separate start/stop points.

  1. Select Menu >> Planter button >> Configure softkey >> Sensor tab.

  2. Select Height from drop-down box.

  3. Select Common.

  4. Completely raise machine in field raised position.

  5. Select Planter Raised button. Select Enter button.

  6. Lower machine completely while driving forward under seeding conditions.

  7. Select Planter Lowered button. Select Enter button.

  8. Select Start/Stop button.

  9. IMPORTANT: Start/stop point must be manually set to 50 for integral planters with single action height switches on row unit parallel arms.

    NOTE: A set point less than 20 is not recommended with wheel frame height sensor.

    With Wheel Frame Height Sensor: From the fully lowered position, raise machine until the desired start/stop point is achieved and select Set Height button. Recommended setting is with openers at soil surface.

  10. If setting needs slight adjustment after planting begins, select input box and adjust value in small increments.

  11. Select Enter button.

Screen Area Information

Planter Configuration - Planter Configuration
Sensor - Sensor
Height - Height
Common - Common
Separate - Separate
Motor Start/Stop Height - Motor Start/Stop Height
Current Planter Height - Current Planter Height
