Calibrate Separate Start and Stop Height
A59325-UN-19FEB07
Menu
A59551-UN-08MAR07
Planter Button
A59172-UN-29JAN07
Configure Softkey
A59528-UN-08MAR07
Planter Raised
A59531-UN-08MAR07
Start/Stop
A59529-UN-09MAR07
Planter Lowered
A59526-UN-08MAR07
Start Height
A59527-UN-08MAR07
Stop Height
H85801-UN-14JUN06
Enter
Use this procedure to set separate points to start and stop RowCommand™ and Variable Rate Drive (VRD) motors as the machine raises and lowers. Machines with wheel frame height sensors use separate start/stop points. Common start/stop points are generally used when machine is equipped with row unit parallel-arm height switches.Select Menu >> Planter button >> Configure softkey >> Sensor tab.
Select Height from drop down box.
Select Separate.
Completely raise machine in field raised position.
Select Planter Raised button. Select Enter button.
Lower machine completely while driving forward under seeding conditions.
Select Planter Lowered button. Select Enter button.
Select Start/Stop button.
IMPORTANT: Start height must be a larger value than stop height.
NOTE: A set point less than 20 is not recommended with wheel frame height sensor.
From the fully lowered position, raise machine until motor stop height is achieved and select Stop Height button. Recommended setting is just before openers exit soil.
Fully raise machine.
From the fully raised position, lower machine until motor start height is achieved and select Start Height button. Recommended setting is just before openers contact soil.
If settings need to be adjusted slightly after planting begins, select input boxes and adjust values in small increments.
Select Enter button.
Screen Area Information
Planter Configuration - Planter Configuration
Sensor - Sensor
Height - Height
Common - Common
Separate - Separate
Motor Start Height - Motor Start Height
Motor Stop Height - Motor Stop Height
Current Planter Height - Current Planter Height
OUO6064,00001B1-19-20100720 |
