Fertilizer Calculator

1. IMPORTANT: Monitor must be completely set up for machine and rate configurations for calculators to function properly.


   A59325-UN-19FEB07

   Menu


   A59551-UN-08MAR07

   Planter Button


   A59174-UN-29JAN07

   Totals Softkey

   Select Menu >> Planter button >> Totals softkey >> Calc tab.

---




2. Select Fertilizer in top drop down box.

3. Select and enter Model from drop down box.

4. Enter fertilizer Rate in input box.

5. Enter Target Speed in input box.

IMPORTANT: Fertilizer suggestions are starting points only.

Fertilizer suggestions are displayed at the bottom of screen.

Screen Area Information

Planter Calculations - Planter Calculations
Calc - Calculator
Fertilizer - Fertilizer
Model - Model
Rate - Rate
gal/ac - Gallons per Acre
Target Speed - Target Speed
mph - Miles per Hour
kph - Kilometers per Hour
Row Spacing - Row Spacing
cm - Centimeters
in - Inches
Pump Drive Range - Pump Drive Range
Lo - Low
Hi - High
Pump Setting - Pump Setting
Nozzle - Nozzle
Expected Pres* - Expected Pressure
*Not valid if using Flow Divider - *Not valid if using Flow Divider
kPa - Kilopascals
psi - Pounds per Square Inch
Orifice - Orifice
