Ground Driven Machines—Target Population and High-Low Warnings

1. IMPORTANT: Population and High-Low warnings are entered differently for variable rate drive machines. See VRD MACHINES—CONFIGURE METER, CROP, DISK, AND RATES in this section.

   NOTE: Number of rows planting are only visible if monitor is configured for a split row machine. See CONFIGURE FRAME, SPLIT ROW, AND DRIVE DISCONNECT WARNING in SETUP Basic Planter Configuration section.


   A59325-UN-19FEB07

   Menu


   A59551-UN-08MAR07

   Planter Button


   A59173-UN-29JAN07

   Rates Softkey

   Select Menu >> Planter button >> Rates softkey.

---




2. Select corn, soybeans, or one of the custom crop names. Select Enter button.

3. Select Target Rate input box and enter value.

4. High and low warning limits are automatically set to a percentage above and below the target rate. To change limits, select High and Low Warning input boxes and enter new value.

   NOTE: Rates and warning setpoints are saved for each crop name.

Screen Area Information

Planter Rates - Planter Rates
Crop Name - Crop Name
Corn - Corn
Soybeans - Soybeans
Custom - Custom
Edit - Edit
Target Rate - Target Rate
High Warning - High Warning
Low Warning - Low Warning
Population Adjust - Population Adjust
Rows Planting - Rows Planting
Avg. Spacing - Average Spacing
Seeds - Seeds
ac - Acre
ha - Hectare
