Warning Messages

A61394
A61394-UN-19NOV07

WARNINGs are the highest level of an alert. Warnings alert the operator to a serious condition. It is recommended the condition causing a warning be corrected before proceeding further. Warnings are displayed as full page messages. Rows not planting is an example of a warning. If a warning is canceled without the condition corrected, a caution is displayed on the bottom line of display as a continued alert. If more than one alert occurs at the same time, a toggle button appears so the operator is able to scroll through alerts.

IMPORTANT: Full page warnings will occur when not on main Planter RUN page to ensure that operator is aware of the issue.

IMPORTANT: When a planter run screen is visible on the display, warning screens will be contained to the portion of the screen the planter occupies. Full screen warnings will occur when a planter RUN screen is not visible on the Display to ensure that the operator is aware of the issue.

A61395
A61395-UN-19NOV07

CAUTIONs are the medium level alert. Cautions alert the operator to conditions that are out of operational limits, but are not serious enough to stop. A population outside of the upper or lower limit is an example of a caution. A warning that has been cleared without correction also appears as a caution. Once a full page caution is cleared, the message remains on a single line at the bottom of the screen until corrected. If more than one alert occurs at the same time, a toggle button appears so the operator is able to scroll through alerts.

IMPORTANT: When a planter run screen is visible on the display, caution screens will be contained to the portion of the screen the planter occupies. Full screen cautions will occur when a planter RUN screen is not visible on the Display to ensure that the operator is aware of the issue.

A61396
A61396-UN-19NOV07

Advisories are the lowest level alert. An advisory alerts the operator to valuable information that is not serious or outside a limit. When a specified target area has been met, an advisory is issued. If more than one alert occurs at the same time, a toggle button appears so the operator is able to scroll through alerts.

OUO6064,0000204-19-20100720
