Lock Up Openers

CAUTION: Hydraulic failure can allow openers to fall rapidly, causing injury or death. To avoid hazard, always lock openers in raised position before adjusting, lubricating or servicing machine.

IMPORTANT: Hydraulic hoses between the lift cylinders and hydraulic lock-up valves should be inspected frequently for wear or damage. Contact your John Deere dealer for replacement hoses.

N39645
N39645-UN-06OCT88

N75663
N75663-UN-05APR07

A - Lock-Up Valve

Fully raise openers and close hydraulic lock-up valve (A).

OUO6074,0000FEB-19-20070405
