Use of Wax-Based Lubricant

A34471-UN-11OCT88

CAUTION: Avoid chemical injury to eyes, skin, or lungs. If using seed treatments, use caution when handling parts coated with seed treatment. Read and follow safety instructions on the chemical treatment label.

IMPORTANT: Only use approved wax-based lubricants. (See your John Deere™ dealer.)

A lubricant (fluency agent) is required for optimum performance of the vacuum meter and CCS™ system (if equipped). To obtain consistent seed release from the seed disk and improve spacing accuracy, properly lubricate the seed.

FARMER-APPLIED SEED TREATMENT

Farmer-applied seed treatments are NOT recommended.

IMPORTANT: Avoid sticky seeds and meter components. It is possible for seeds to become sticky due to chemical reactions between farmer-applied seed treatments and commercially applied treatments. If farmer-applied treatments are used, follow recommendations of chemical manufacturer carefully. Avoid treatments with high oil content. Certain temperature and humidity levels also complicate material compatibility.

If farmer-applied treatment is used, apply seed treatment to seed before the lubricant and allow seed treatment to dry before placing seed in tanks. If seed treatment accumulates in the meter while using the following lubricant application rates, contact the treatment manufacturer for assistance.

IMPORTANT: Avoid poor seed flow. Thoroughly incorporate lubricant (fluency agent) in tanks and hoppers until all seeds are evenly coated.

Seed must be free of clumps.

COMMERCIALLY TREATED SEED

Some treated seed is coated with commercially applied lubricant. To maintain meter performance, apply the recommended amount of lubricant (fluency agent), in addition to the commercial application.

Application Rate of Approved Fluency Agents in CCS™ Tanks
Apply fluency agents to seed as seed enters tank. All seeds must be coated to ensure movement through the CCS™ system and for proper meter performance. Mix seed and lubricants as necessary.
CCS™ Tank Size	Quantity of Wax-Based Agent
1233 L (35 bu.) Bulk Tank	0.9 L (4-1/2 cups)
1762 L (50 bu.) Bulk Tank	1.2 L (6-1/2 cups)
Per 80 000 kernel seed unit	24 mL (1/8 cup)

Adjust these rates as necessary so all seeds become coated with lubricant, while avoiding an accumulation of lubricant in bottom of tank.

IMPORTANT: Avoid the formation of lubricant clumps. Clean buildup of seed treatments and lubricant (fluency agent) out of hoppers between fills.

If lubricant builds up in bottom of hopper and vacuum tubes require frequent cleanout, reduce lubricant rate. If a coating of seed treatment is found on seed disks, increase the amount of lubricant.

When using seed treatments, clean meters and seed disks as needed. Clean Seed disks with warm, soapy water. Spray a graphite solution on vacuum seal side of disk as needed.
