VRD Motor/Valve Flush

A59325-UN-19FEB07

Menu

A59551-UN-08MAR07

Planter Button

A59567-UN-08MAR07

Diagnostic Softkey

1. Select Menu >> Planter button >> Diagnostics softkey >> Tests tab.

2. Select VRD Motor/Valve Flush from drop down box.

3. Select Flush Time input box and enter a value of 1, 2, or 3 seconds.

4. Plant at a speed greater than 4 km/h (2 mph).

   Motors operate for duration indicated and flush air from system.

Screen Area Information

Planter Diagnostics - Planter Diagnostics
Tests - Tests
VRD Motor/Valve Flush - Variable Rate Drive Motor/Valve Flush
Ground Speed - Ground Speed
mph - Miles per hour
kph - Kilometers per hour
Flush Time - Flush Time
secs - Seconds
Flush RPM - Flush revolutions per minute
Motor - Motor
Quick Start - Quick Start
Auto - Auto
Manual - Manual
Speed must be greater than 4 kmh (2 mph) - Speed must be greater than 4 km/h (2 mph)
speed needs to be increased - speed needs to be increased
Value out of range - Value out of range
