Configure Separate Start and Stop Height

A59671-UN-14JAN08

Air Cart Button

A59528-UN-08MAR07

Tool Raised

A59672-UN-14JAN08

Configuration Softkey

A59529-UN-09MAR07

Tool Lowered

A59531-UN-08MAR07

Start, Stop

A59526-UN-08MAR07

Start Height

A59527-UN-08MAR07

Stop Height

1. Select primary Menu button >> Air Cart button >> Configuration softkey >> Sensor tab.

2. Select Height from drop-down box.

3. Completely raise tool in field raised position.

4. Select Tool Raised button. Select Enter button.

5. IMPORTANT: Value must be established at deepest tool depth not seeding depth. Note current setting then adjust depth control to allow tool to fully lower.

   Lower tool completely while driving forward under seeding conditions.

6. Select Tool Lowered button. Select Enter button.

7. Select Start and Stop button.

8. IMPORTANT: Start height must be a larger value than stop height.

   From the fully lowered position, raise tool until stop height is achieved and select Stop Height button. The recommended stop height is just before openers exit soil.

9. Fully raise machine.

10. From the fully raised position, lower tool until start height is achieved and select Start Height button. The recommended start height is just before openers contact soil.

11. To adjust start and stop height slightly after seeding begins, select input box and adjust value in small increments.

12. Select Enter button.

13. Return tool depth control to original setting.

Screen Area Information

Air Cart - Air Cart
Cart - Cart
Configuration - Configuration
Sensor - Sensor
Height - Height
Common - Common
Separate - Separate
Current tool height - Current tool height
% - Percentage
