System Tests

1.
   A59671-UN-14JAN08

   Air Cart Button


   A59325-UN-19FEB07

   Primary Menu Button


   A59567-UN-08MAR07

   Diagnostics


   A62334-UN-26MAR08

   On and Off


   A59369-UN-20FEB07

   Zero Button

   Select primary Menu button >> Air Cart button >> Diagnostic softkey >> System Tests button >>Continue (Enter) button in top right corner.

---




2. Page two displays the fan speed light test. Select the on and off button next to each light while watching lights on front of cart for illumination.

3. Select Continue (Enter) button.

4. Page four tests tire speed, fan speed, and tank level inputs. Select the Test button next to Tire Speed.

5. NOTE: Configure tire sensor first. (See CONFIGURE TIRE SPEED SENSOR in Monitor Setup for Air Cart section.)

   Mark a spot on the rear tire of cart.

   1. Drive cart forward while a second person watches mark or place rear corner of cart on jack stand and turn tire by hand. Select on and off switch to start pulse count.

   2. When tire completes one full revolution, select on and off switch to stop pulse count.

   3. The actual count is displayed next to Pulse Counts. Fifty-one pulses are expected per revolution.

6. Select Continue (Enter) button.

7. Select the Test button next to Tank Level.

8. As each level sensor inside a tank is pressed, the switches (Sw's) column changes from zero to one then two then three. Each switch must remain pressed for the numbers to increase.

9. Select Continue (Enter) button.

10. Page five tests SectionCommand™. Select the All On button to turn all the sections on. Select the All Off button to turn off all of the sections.

11. To select each section individually check the box for the corresponding section. Once desired sections are selected press the Send button to test the sections.

12. Select Continue (Enter) to display results.
