Master Module Information

1.
   A62045-UN-14FEB08

   Blockage Button


   A59567-UN-08MAR07

   Diagnostic Softkey

   Select Menu >> Blockage button >> Diagnostic softkey >> Readings tab.

---




2. Select Master Module from drop-down menu.

   This screen displays hardware and software information, seed sensor power level, and electronic control unit power level.

Screen Area Information

Diagnostics - Diagnostics
Readings - Readings
Master Module - Master Module
Software Part Number - Software Part Number
Software Version Number - Software Version Number
Hardware Part Number - Hardware Part Number
Hardware Serial Number - Hardware Serial Number
SNSR PWR - Sensor Power
ECU PWR - Electronic Control Unit Power
Volts - Volts
