Standard Buttons

A59325
A59325-UN-19FEB07

Primary Menu

H85801
H85801-UN-14JUN06

Enter or Continue

H85814
H85814-UN-14JUN06

Cancel

H85815
H85815-UN-14JUN06

Clear

H85816
H85816-UN-14JUN06

Previous

A59323
A59323-UN-22FEB07

Back

A59322
A59322-UN-19FEB07

Toggle

Become familiar with these buttons. These buttons have standard functions and are used periodically throughout the screens.

  • Primary Menu: Displays primary menu showing buttons for various functions.
  • Enter: Enter a value or selection into memory. Continue to next step of procedure.
  • Cancel: Cancels the current screen or selection.
  • Clear: Clears a value to zero or erases a selection.
  • Previous: Returns to previous screen or selection.
  • Back: Moves cursor back one space.
  • Toggle: Alternates a selection back and forth.

OUO6074,0000FA6-19-20081016
