Configure Date and Time

1.
   A59565-UN-08MAR07

   Display Button


   A59592-UN-15MAR07

   Settings Softkey

   Select Menu >> Display button >> Settings softkey.

---




2. Select Time/Date tab.

3. Select each Date drop down box and choose the month, day, and year.

4. Select Date Format drop down box and choose desired format.

5. If area is currently observing daylight saving time, select Daylight Savings Time check box to display a check. When daylight saving changes, select this box to change hour reading instantly.

6. To use a 24 hour clock, select 24 Hour Clock check box to display a check.

7. Select Time input boxes and enter an hour and minute. Select a.m. or p.m. from drop-down box.

8. If equipped with GPS, perform the following:

   1. Select GPS Time Sync check box to synchronize time.

   2. Select GMT Offset drop down box and select a number representing the number of hours current location varies from Greenwich Mean Time.

   3. Select Local Offset drop down box and enter the number of minutes current location is past local time zone.

Screen Area Information

Display Settings - Display Settings
Time/Date - Time and Date
Date - Date
Date Format - Date Format
MM - Month
DD - Day
YYYY - Year
Time - Time
24 Hour Clock - 24 Hour Clock
Daylight Savings Time - Daylight Savings Time
GMT Offset - Greenwich Mean Time Offset
Local Offset - Local Offset
GPS Time Sync - Global Positioning System Synchronization
