Using High-Pressure Washers

IMPORTANT: High-pressure washers are a very effective means of cleaning the tractor. To avoid damage to the tractor, do not go closer than 80 cm (32 in.) and spray at an angle between 45 and 90° when cleaning sealing surfaces, seals and decals. Maximum pressure must not exceed 12000 kPa (120 bar; 1740 psi).

Do not, under any circumstances, spray or wash components (e.g. the engine) with cold water when hot. Do not use rotary nozzles or water at temperatures over 50°C (122°F). Cooling units, the hitch jaw, bearings and electronic/electrical equipment must not be cleaned with high-pressure washers. Follow the instructions in the high-pressure washer operator's manual and manuals of attached equipment.

OU12401,0001B8B -19-13MAR09-1/1
