Every 250 Hours

L112122-UN-05SEP94

Lights - Check that all lights (including headlights) are functioning properly Fuel system - Drain water and sediment from fuel filter Engine - Remove contaminant from area surrounding the engine Cooling system/air-conditioning system - Clean the radiator and condenser, fins and screens Check brakes Check the leak-off oil container (if equipped) Transmission/hydraulic system - Check oil level Check the engine oil level Cooling system - Check level of coolant Three-point hitch - Lubricate lift links and rockshaft Front axle - Lubricate pivot bearing Front-wheel drive axle - Lubricate all universal joints including u.j. shaft from transmission to front-wheel drive axle Front wheel drive axle with TLS - Lubricate Panhard link and hydraulic cylinder Access the diagnostic trouble codes, rectify faults and then delete the diagnostic trouble codes Check the neutral start circuit PTO actuation - Check safety device Lights - Check settings of headlights Load center - Visually inspect and clean Fuel system - Drain water and sediment from fuel tank Front axle without front-wheel drive - Tighten bolts

Wheels - Front and rear wheels, check torques of attaching bolts Wheels - Wheel disk to rim, check torques of attaching screws Wheels - Wheel weights, check torques of attaching screws Wheels - Dual wheel attachment, check torques of attaching screws (see manufacturer's specifications) Cab - Cab mountings, check torque of fixing screws Cab - Ground cable, check torque of fixing screws Drawbar - Check torques of fixing screws Front loader - Mounting frame, check torques of attaching screws Check oil level - Front-wheel drive axle, axle housing Check oil level - Front-wheel drive axle, final drives Air intake hoses, check for leaks Foot brake, operational check Emergency brake, operational check Park lock, operational check Drawbar - Check all components for wear; check that all components function properly Front axle without front-wheel drive - Lubricate the grease fittings Lubricate pivoting fenders, and perform operational check Suspended cab, lubricate the grease fittings on suspension system Rear PTO, lubricate stub shaft support (with turnable stub shaft)
