Changing Cab Air Filters and Recirculation Air Filters

LX1057568-UN-12JUL12

LX1057565-UN-12JUL12

LX1057566-UN-12JUL12

CAUTION: It is not permitted to clean the air filter if the cabin has been retrofit with activated carbon filters. Activated carbon filters have to be replaced with new ones.

Remove cab air filter (B) and recirculation air filters (D) on both sides, and replace them with new ones.

To do this, first remove covers (A) and (C), then remove the filters.

Re-install in reverse order.

Before closing the cover, make sure that the fresh air filter element is correctly installed in its groove.

IMPORTANT: Change cab air filters every 1500 hours or 2 years.

NOTE: If the cab has been retrofitted with activated carbon filters, a service interval of 500 operating hours or once every year at the latest applies.
