Shift the PowrQuad Transmission

LX1042987-UN-09JUL07

LX1057604-UN-07SEP12

A - Range-Shift Lever

B - Gear-Shift Lever

C - Reverser Lever

Gears are shifted by means of gear-shift lever (A), range-shift lever (B) and reverser lever (C).

NOTE: After the engine has been started wait for 5 seconds before moving the reverser lever (C) out of neutral position.

The clutch pedal must be depressed to change the ranges. There is no need to depress the clutch pedal to shift gears or to change the direction of travel.

CAUTION: If the reverser lever is actuated when the engine is running and a range is selected, the tractor will start to move.

IMPORTANT: Engage park lock only when the tractor is stationary.

Optimum gear-shifting for driving under load (transport):

1. Select a range suitable for driving under load.
2. Engage the first gear.
3. Drive and shift up through the ranges until the top range is reached.
4. Shift up through the gears.
