Engine - Remove any dirt from area surrounding the engine
-
Cooling system/air-conditioning system - Clean the radiator
and condenser, fins and screens
-
Fuel filter - Drain water and residues
-
Retrieve the diagnostic trouble codes, rectify errors, and then
delete the diagnostic trouble codes
-
Lights - Check that all lights and headlights are functioning
properly
-
Drawbar - Check torques of attaching screws
-
John Deere™ front loader mounting frame - Check torques
of attaching screws (see operator's manual and installation instructions
of the front loader)
-
Cooling system - Check level of coolant
-
Check air intake hoses for leaks
-
Transmission/hydraulic system - Check oil level
-
Check leak oil tanks (if equipped)
-
Check brakes
|
-
Change the engine oil filter
-
Change engine oil
-
Change hydraulic filter
-
Change transmission oil filter
-
Front-wheel drive axle - Final drives with brake, oil change
-
Front-wheel drive axle, final drives without brake - Oil change
-
Front-wheel drive axle - Axle housing, oil change
-
Adjustable front axle - Lubricate the grease fittings
-
Front-wheel drive axle - Lubricate pivot bearing
-
Front-wheel drive axle - Lubricate all universal joints including
universal-jointed shaft from transmission to front-wheel drive axle
-
Suspended front-wheel drive axle - Lubricate hydraulic cylinder
-
Universal-jointed shaft between engine and transmission (if
equipped) - Lubricate all U-joints
-
Cab suspension - Lubricate the lubrication points
-
Three-point hitch - Lubricate lift links and rockshaft
-
Lubricate the rear axle bearings (if equipped)
-
Lubricate the draft link bearings (if equipped)
|
