Front Hitch - Hook-Type Center Link

LX1033643-UN-17MAY04

LX234778-UN-30NOV15

A - Control Console

B - Ball

C - Pin

This center link is intended for category III balls.

IMPORTANT: The matching ball has to be used.

Category	Ball diameter (a)
III	60 mm (2.4 in.)

Hook operation

With control element (A), the hook can be operated manually.

IMPORTANT: Make sure that the hook is locked correctly:

The control element (A) has to lie against the hook completely, the ball (B) must not have any noticeable play and the pin (C) has to lock around the ball.
