Lighting System - Front Loader Worklights (If Equipped)

IMPORTANT: It is not permitted to use worklights on public roads.

If the engine is switched off, the worklights remain on and do not automatically switch off. If the engine is going to be in standstill for an extended period, switch off the worklights in advance.

LX1056630-UN-26JUN12

Light Switch

LX234604-UN-19MAR15

1 - Lights Switched Off

2 - Parking Lights Switched On (Clearance and Tail Lights)

3 - Headlights Switched On

4 - Headlights Switched On and Worklights can be Switched On

A - Light Switch

D - Worklights on Front Loader (If Equipped)

Worklights on the front loader can be switched on and off using switch (D) provided light switch (A) is set to position 4.
