Lighting System - Front Loader Worklights (If Equipped)

IMPORTANT: It is not permitted to use worklights on public roads.

LX1056630-UN-26JUN12

Light Switch

LX266709-UN-13JAN16

1 - Lights Switched Off

2 - Parking Lights Switched On (Clearance and Tail Lights)

3 - Headlights Switched On

4 - Headlights Switched On and Worklights can be Switched On

A - Light Switch

B - Worklights on Front Loader (If Equipped)

Worklights on the front loader can be switched on and off using switch (B) provided light switch (A) is set to position 4.
